15-17.3 inch Capacitive Touch Screens
15.6 inch BOE PCAP, Interactive Touch Screen - NV156FHM-A21
Product Specification:
- Model : NV156FHM-A21
- Size : 15.6 inch
- Resolution : 1920*1080
- Brightness : 270 cd/m2 (Typ.)
- Touch work ability : 10 points
- Application : Laptop
| Specifications: | |
| TFT LCD Panels | |
| Size: | 15.6 inches (diagonal) |
| Resolution: | 1920*1080 |
| Active Area: | 346.23 × 195.54 (H×V) |
| Brightness: | 270 cd/m2 (Typ.) |
| View Angle: | 85/85/85/85 (Typ.)(CR≥10) |
| Contrast Ratio: | 800:1 (Typ.) (TM) |
| Interface: | eDP |
| Frequency: | 60Hz |
| Backlight Lifetime: | 10K hours |
| Voltage input: | 3.3V (Typ.) |
| LED driver: | Included |
| Touch Specifications | |
| Touch Type: | Capacitive Touch |
| Multi Touch Points: | 10 points |
| Active Touch Area: | Same as LCD A/A |
| Touch IC: | eKTH3915SU |
| Interface: | USB, I2C |
| Support OS: | Win7,Win8,Win10 |
| Tempered Glass Surface Hardness | 7H |
| Sensor Type | OGS |
| Environment | |
| Operation Temperature | -30 ~ 85 °C |
| Storage Temperature | -30 ~ 85 °C |
| Humidity condition Operation: | Ta=40 °C,90%RH |
| Adhesive types of LCD Panel and Touch | |
| Full Optical Bonding | |
| Stablity Test includes: | |
| 1). High / Low Temperature Storage Test | |
| 2). High / Low Temperature Operation Test | |
| 3). High Humidity Operation and StorageTest | |
| 4). Thermal Shock Test (non-operating) | |
| Warranty: | |
| 1). Warranty Period: 2 years from the date of shipping. | |
| 2). Warranty Exclusions: | |
| * Failure to adhere to the handling, storage, operating, assembly or other procedures and | |
| Parameters outlined in this delivery specification. | |
| * Accidental or purposeful abuse, neglect or acts of nature. | |
| * Breakage or physical scratches to the touch screen. | |
| * Other factors beyond the control of JFCVision | |
