10.1-12.3 inch Capacitive Touch Screens
10.1 inch Touch Screen, Touch Screen Touch
Product Specification:
- Model : JFC101CMYY.V0
- Size : 10.1 inch
- Resolution : 1920*800
- Brightness : 400 cd/m2 (Typ.)
- Application : Industrial and Commercial Display
| JFCVision 10.1 inch LCD Touchscreen Features a Slim Design | |
| TFT LCD Panels | |
| Size: | 10.1inches (diagonal) |
| Resolution: | 1920*800 |
| Active Area: | 216.96*135.6mm (H*V) |
| Brightness: | 400 cd/m2 (Typ.) |
| View Angle: | 85/85/85/85 |
| Contrast Ratio: | 800:1 |
| Interface: | LVDS (1 ch,8-bit),40pin |
| Frequency: | 60Hz |
| Backlight Lifetime: | 30K hours |
| Voltage input: | 3.3V (Typ.) |
| LED driver: | included |
| Touch Specifications | |
| Touch Type: | Capacitive Touch, with 2-glass solution technology (2GS) |
| Multi Touch Points: | 10 points |
| Outline Dimension | 520*306 (mm) |
| Active Touch Area: | Same as LCD Panel's active area |
| Touch IC: | EEIT |
| Touch Control Interface: | USB 2.0 |
| Touch Control Board: | Included |
| Systems Supportable: | Android, Windows, Linux |
| Tempered Glass Surface Hardness | 7H (Typ.) (Customized) |
| Transmittance: | > 85 °C |
| Touch Supportable: | Finger, Glove or Passive Pen Input |
| Input Voltage | 3.5V~5.5V, Typ. 5V |
| Environment | |
| Operation Temperature | -10 ~ 50 °C |
| Storage Temperature | -20 ~60 °C |
| Humidity: | 95% at 60 °C RH, no condensing |
| Adhesive types of LCD Panel and Touch | |
| 3M fasten | |
